720-1020MHz 100W GaN Drone Jammer Module – Wideband Interference Solution for UAV Countermeasures

High-Power 720-1020MHz GaN Drone Jammer Module – 100W Output for Reliable UAV Countermeasures In the evolving landscape of unmanned aerial systems, effective and robust counter-drone technology is essential. Our 720-1020MHz GaN-based jammer module delivers high-performance interference in a compact, durable design. Built with AB-class GaN-on-SiC technology……

Send Inquiry

100W

Functional characteristics

High-Power 720-1020MHz GaN Drone Jammer Module – 100W Output for Reliable UAV Countermeasures

In the evolving landscape of unmanned aerial systems, effective and robust counter-drone technology is essential. Our 720-1020MHz GaN-based jammer module delivers high-performance interference in a compact, durable design. Built with AB-class GaN-on-SiC technology and mounted on a copper carrier, this module ensures superior thermal management and stable operation under demanding conditions.

Key Features & Benefits
- Frequency Range: Covers 720–1020MHz, optimized for disrupting drone communication and control links.
- High Power Output: 50±1dBm (100W) output ensures reliable jamming over extended distances.
- GaN Technology: AB-class GaN design offers high efficiency, wide instantaneous bandwidth, and excellent thermal performance.
- Compact & Lightweight: Measures only 150×80×22mm and weighs approximately 800g, suitable for portable and fixed systems.
- Enhanced Reliability: Operates within -20°C to +65°C, with protection against over-voltage and overheating.
- Customizable Options: Adjustable scanning speed (100–500KHz) and support for various input sources (VCO, DDS, SDR).
Technical Specifications
- Operating Voltage: 28–32V DC
- Operating Current: ≤9.2A
- Output Power: 100W (50±1dBm)
- Scanning Speed: 270KHz (customizable)
- Connector: N-type female
- Indicators: Power, over-voltage, over-temperature
- Input Source: Built-in high-speed noise-modulated signal source
Applications
This module is designed for security, defense, and critical infrastructure protection where unauthorized drone activities pose a risk. It can be integrated into:
- Portable anti-drone systems
- Fixed-site perimeter protection
- Mobile security vehicles
- Custom counter-UAV solutions
Why Choose Our Module?
Our jammer module leverages patented thermal design and GaN technology to deliver consistent performance in a wide range of environments. With optional customization and a focus on ruggedness, it meets the needs of professional operators seeking reliable drone mitigation.

Ordering & Customization
We offer tailored solutions, including frequency adjustments, signal source options, and scanning speed modifications. Contact us to discuss your specific requirements.
