2000-2400MHz 50W High-Power Drone Jammer Module | Signal Blocker

GW-2000-2400MHz High-Power Drone Jammer & Signal Interference Module Our GW series high-power module is engineered for effective radio frequency interference within the 2000-2400MHz spectrum. This robust 50W output jammer is specifically designed to counter unauthorized drones and disrupt LORA (Long Range) and LDMOS-based communication links, providing……

Send Inquiry

50W

Functional characteristics

GW-2000-2400MHz High-Power Drone Jammer & Signal Interference Module

Our GW series high-power module is engineered for effective radio frequency interference within the 2000-2400MHz spectrum. This robust 50W output jammer is specifically designed to counter unauthorized drones and disrupt LORA (Long Range) and LDMOS-based communication links, providing a reliable solution for critical security and perimeter protection applications.

Core Features & Advantages

High-Power Output: Delivers a potent 50W (47±1dBm) output power for maximum effective range and reliable signal suppression.
Targeted Frequency Range: Precisely covers the 2000-2400MHz band, commonly used by consumer drones, some data links, and LORA devices.
Advanced Interference Technology: Utilizes a built-in high-speed noise modulation signal source with a rapid 270KHz scanning speed, effectively disrupting target signals.
Robust & Reliable Design: Operates in a wide temperature range (-20°C to +65°C) and features protection against over-voltage and over-temperature conditions, ensured by clear LED indicators.
High Customization Flexibility: Key parameters including scanning speed (100-500KHz), input signal source (VCO, DDS, SDR), voltage, and physical dimensions can be customized to meet specific project requirements.

Technical Specifications

Parameter	Specification
Frequency Range	2000 – 2400 MHz
Output Power	50W (47 ±1 dBm)
Operating Voltage	24-28V DC (Standard 28V)
Operating Current	≤ 3.2 – 4.5 A
Modulation / Signal Source	Built-in High-Speed Noise Modulator (Customizable: VCO, DDS, SDR)
Scanning Speed	270 KHz (Customizable: 100 – 500 KHz)
Operating Temperature	-20°C ~ +65°C
RF Connector	SMA Female
Dimensions	117 x 58 x 18 mm (Customizable)
Weight	Approx. 300g
Indicators	Power, Over-Voltage, Over-Temperature

Typical Applications

This module serves as a core component for building integrated counter-drone and communication shielding systems:

Drone Defense Systems: Deploy in fixed-site or mobile platforms to protect sensitive areas from unauthorized UAV incursions.
LORA Network Security: Shield specific zones from unwanted LORA packet transmission for data security.
Communication Restriction: Disrupt specific wireless links in the 2.4GHz band for security purposes.
Custom RF Interference Solutions: Integrated into broader electronic warfare or signal management systems.

Ordering & Customization

The standard GW module is ready for integration. We specialize in tailoring solutions to match your exact needs. Contact our technical team to discuss customizations in frequency, power, scanning pattern, form factor, or control interface.
